Wireless Security Settings

Updated Jan 30, 2024 ·

Wi-Fi Security Standards Comparison

FeatureWEPWPAWPA2WPA-PSK (Personal)WPA2-Enterprise
EncryptionRC4TKIPAES (CCMP)TKIP or AESAES (CCMP)
AuthenticationShared keyPSKPSKPre-Shared Key (passphrase)802.1X + RADIUS server
Security LevelVery weak (obsolete)Weak to mediumStrongMedium to highStrong
Key ManagementStatic keyStatic keyStatic keyShared keyDynamic per user/session
Setup ComplexitySimpleSimpleSimpleEasy (home use)Complex (enterprise-grade)
Recommended?❌ Not recommended❌ Outdated✅ Yes (if WPA3 not available)✅ Yes (for home)✅ Best for organizations

WEP (Wired Equivalent Privacy)

WEP was the first Wi-Fi encryption standard but is now considered insecure and outdated.

  • Uses fixed encryption keys shared across all devices
  • Available in 64-bit and 128-bit key sizes
  • Weak 24-bit initialization vector makes it easy to crack
  • No longer recommended for protecting wireless networks

WPA (Wi-Fi Protected Access)

WPA uses TKIP (Temporal Key Integrity Protocol) to generate dynamic keys.

  • Adds message integrity to detect tampering
  • Still relies on flawed cryptographic methods
  • Insecure, due to insufficient data integrity checks in TKIP.

WPA is more secure than WEP, but not strong enough for modern networks.

WPA2

WPA2 improved security significantly and became the long-term Wi-Fi standard.

  • Replaces TKIP with AES (Advanced Encryption Standard) for strong encryption
  • Considered secure for many applications, though WPA3 is now preferred.

WPA2 uses CCMP (Counter Cipher Mode with Block Chaining Message Authentication Code Protocol) for data integrity and confidentiality.

WPA2-PSK

WPA2-PSK is the personal-use version of WPA2, commonly used in homes and small businesses.

  • Uses a shared passphrase to generate the Pairwise Master Key (PMK)
  • PMK is the foundation for encrypting communication between device and router

This method is simple to set up, but in this setup, all users share the same key

  • Easier to manage but less secure in environments with many users
  • Still widely used despite some risks

WPA2-Enterprise

WPA2-Enterprise is a secure Wi-Fi setup designed for businesses and organizations. It focuses on strong user authentication and network access control.

  • Uses 802.1X with a RADIUS server to verify each user
  • Assigns a unique encryption key to each session
  • More secure than WPA2-PSK, especially for large networks
info

WPA2-Enterprise doesn't directly manage transport-layer security, which is where PEAP and its TLS tunneling come into play.

WPA3

WPA3 is the latest security protocol for Wi-Fi networks, designed to provide stronger data protection and improve security against attacks.

  • Provides improved encryption for safer wireless communication.
  • Protects against brute-force password guessing attacks.
  • Supports individual encryption per device to enhance privacy.

WPA3 also introduced advanced security features like SAE, Enchanced Open, and AES-GCMP.

SAE

This protocol allows both the client and access point to authenticate each other using a shared password, without transmitting the password in plain text or exposing it to potential attackers during the authentication process.

  • Resists offline dictionary attacks
  • Provides better security than traditional PSK
  • Uses Diffie-Hellman for secure key exchange
  • Replaces the vulnerable 4-way handshake used in WPA2

With SAE, even if attacker captures the data required for the handshake, it cannot be used to derive the password or decrypt the session.

Password Authenticated Key Exchange (PAKE)

WPA3's SAE method is based on Password Authenticated Key Exchange (PAKE) protocol, which ensures secure mutual authentication.

  • Both sides confirm knowledge of the password without revealing it
  • Protects against attackers trying to guess passwords by observing the exchange

Dragonfly Handshake

SAE uses the Dragonfly handshake, which includes a MAC address hash to strengthen authentication and resist key recovery.

  • Each handshake exchange is unique, even with the same password
  • Blocks precomputed dictionary and rainbow table attacks
  • Binds authentication to the device’s MAC address
  • Makes impersonation and key recovery significantly harder

Hash-to-Element (H2E)

WPA3-SAE also utilizes a Hash-to-Element (H2E) method for password derivation, which replaced the earlier Hunting-and-Pecking method due to security concerns.

Enhanced Open/OWE

Enhanced Open/OWE (Opportunistic Wireless Encryption) adds encryption to open Wi-Fi networks without passwords.

  • Secures communication even without user authentication
  • Prevents eavesdropping on public networks
  • Improves privacy in cafes, airports, and other open environments

AES GCMP

AES-GCMP (Advanced Encryption Standard Galois/Counter Mode Protocol) improves performance and security in WPA3 networks.

  • Supports 128-bit AES for personal networks.
  • Supports 192-bit AES for enterprise networks.
  • Ensures both data confidentiality and integrity.
  • Supports high-efficiency encryption in Wi-Fi networks.

This makes GCMP suitable for high-performance and security-sensitive environments.

Management Frame Protection

This WPA3 feature secures network management traffic from key recovery attackS.

  • Protects against spoofing, tampering, and Denial of Service attacks
  • Secures vulnerable frames used to manage Wi-Fi connections
  • Prevents attackers from disrupting or impersonating devices

WPS

Wi-Fi Protected Setup (WPS) is a network security standard that aims to simplify the process of connecting devices to a wireless network, but it has known vulnerabilities.

  • Must have a WPS-capable WAPs and devices.
  • Press button on both the WAP and device, to create a WPA2-encrypted connection.
  • Easy to crack, more and more devices will drop support for it.
  • Advisable to disable WPS in favor of stronger security measures like WPA3.

Methods:

  • Push Button Method - Users press a physical button on the router to connect devices.
  • PIN Method - Involves entering an 8-digit PIN, which is susceptible to brute-force attacks.
  • NFC Method - Connects devices via Near Field Communication; easier access but limited security.
info

WPS (Wi-Fi Protected Setup) is not a wireless security standard like WEP, WPA, or WPA2. Instead, it’s a connection method designed to simplify the process of connecting devices securely to a Wi-Fi network.

AAA

AAA (Authentication, Authorization, and Accounting) is a framework used in network management to control access and usage, ensuring secure network operations.

  • Authentication: Verifies the identity of users or devices.
  • Authorization: Grants access based on permissions.
  • Accounting: Monitors and logs user activities for security auditing.

For more information, please see AAA of Security

RADIUS

RADIUS (Remote Authentication Dial-In User Service) is a protocol used for network access authentication, authorization, and accounting, commonly employed in enterprise networks.

  • Widely used to manage network access for employees, contractors, and guests.
  • Enhances security by providing a secure method for authentication.

For more information, please see RADIUS

TACACS+

TACACS+ (Terminal Access Controller Access-Control System Plus) separates the functions of AAA to allow for a more granular control over processes.

  • Similar to RADIUS, but allows for more detailed control over AAA functions.
  • This level of separation permits the distinct handling of each component across different services.
  • Uses TCP and encrypts authentication for improved security over older AAA protocols.

For more information, please see TACACS+

EAP

EAP (Extensible Authentication Protocol) is a flexible authentication framework frequently used in network access control, providing various methods for secure authentication.

  • Supports multiple authentication methods, including passwords and certificates.
  • Facilitates secure access in enterprise networks.
  • Commonly used in wireless networks for enhanced security.

For more information, please see EAP Variants
