Access Logs

Updated Feb 05, 2023 ·

Overview​

Access logs record details about who uses your service and what happens during their requests.

  • They show if requests succeed or fail.
  • These logs help track user activity and build web analytics.

They capture informatioon such as:

  • Visitor’s IP address
  • Requested path
  • Response status (like 200 or 404)

Configuring Access Logs​

You can set access logs similarly to Traefik logs by adjusting:

  • File path and log format.
  • Buffer size to control performance.
  • Filters to log only certain status codes, retries, or slow requests.

For example, filter out all 200 status logs and only show errors like 404 or 500 to quickly find problems.

Managing Access Logs​

Good log management keeps your logs clean and useful.

  • Limit or include specific header fields to reduce clutter.
  • Use log rotation to prevent large log files from filling storage.
  • Adjust time zone settings from default UTC to your preferred zone.

Lab: Enabling Access Logs​

This lab shows how to enable access logs in Traefik.

Clone the Repository​

Github repo: joseeden/labs-traefik

Clone the project repository from GitHub.

git clone https://github.com/joseeden/labs-traefik.git
cd labs-traefik/05-middleware/06-observability/01-traefik-logs

Project structure:

06-observability
└── 01-traefik-logs
    ├── docker-compose.access-log.yml
    ├── traefik.access-log.yml

Create the Usersfile​

info

The usersfile will be used for testing access logs when basic authentication is active.

To create hashed passwords, install the tool htpasswd:

sudo apt install -y apache2-utils

Generate a hash with this command:

htpasswd -nb your-username 'add-password-here'

For example:

htpasswd -nb michaelscarn 'thatswhatshesaid'

Expected output:

michaelscarn:$$apr1$$FAa3Qsw4$$uQ8qtFNTfLLmG6ohrK.qS.

Next, create the users_file in the same folder as the Docker compose file. Put all hashed credentials here, one user per line:

echo "michaelscarn:$$apr1$$FAa3Qsw4$$uQ8qtFNTfLLmG6ohrK.qS." >> users_file

Add users_file to your .gitignore file to keep it out of Git:

echo "users_file" >> .gitignore

Your directory should now contain all these files:

06-observability
└── 01-traefik-logs
    ├── .gitignore
    ├── docker-compose.log.yml
    ├── traefik.yml
    └── users_file

Review the Files​

info

We'll start with testing access logs without authentication first.

The traefik.yml file sets up Traefik with access logging enabled.

api:
  dashboard: true
  insecure: true

providers:
  docker:
    exposedByDefault: false

# enable Access logs
accessLog: {}

log:                  # DEBUG, PANIC, FATAL, ERROR, WARN, and INFO
  level: INFO

entryPoints:
  web:
    address: ":80"
  websecure:
    address: ":443"

To view logs, we will also deploy a catapp service using the docker-compose.log file..

version: "3"

services:
  traefik:
    image: traefik:v2.3
    ports:
      - "80:80"
      - "443:443"
      - "8080:8080"
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock
      - ./traefik.access-log.yml:/etc/traefik/traefik.yml

  catapp:
    image: mikesir87/cats:1.0
    labels:
      - "traefik.enable=true"
      # Routers
      - "traefik.http.routers.catapp.rule=Host(`catapp.localhost`)"
      - "traefik.http.routers.catapp.service=catapp"
      - "traefik.http.routers.catapp.entrypoints=web"
      - "traefik.http.routers.catapp.middlewares=test-compress,test-errorpages"
      # Services
      - "traefik.http.services.catapp.loadbalancer.server.port=5000"
      # Compress Middleware
      - "traefik.http.middlewares.test-compress.compress=true"
      # Error Pages Middleware
      - "traefik.http.middlewares.test-errorpages.errors.status=400-599"
      - "traefik.http.middlewares.test-errorpages.errors.service=error"
      - "traefik.http.middlewares.test-errorpages.errors.query=/{status}.html"

  # Error Page service
  error:
    image: guillaumebriday/traefik-custom-error-pages
    labels:
      - "traefik.enable=true"
      - "traefik.http.routers.error.rule=Host(`error.localhost`)"
      - "traefik.http.routers.error.service=error"
      - "traefik.http.services.error.loadbalancer.server.port=80"
      - "traefik.http.routers.error.entrypoints=web"

Deploy the Stack​

Deploy the stack using:

docker stack deploy -c docker-compose.access-log.yml traefik

Expected output:

Creating network traefik_default
Creating service traefik_traefik
Creating service traefik_catapp
Creating service traefik_error

Testing the App​

Access the catapp application on your browser and refresh a few times.

http://catapp.localhost/

View logs with:

docker service logs traefik_traefik

The logs will show request details including IP, HTTP method, response code, destination, and response time.

| 10.0.0.2 - - [11/Aug/2022:02:06:44 +0000] "GET / HTTP/1.1" 200 659 "-" "-" 1 "catapp@docker" "http://10.0.1.6:5000" 14ms
| 10.0.0.2 - - [11/Aug/2022:02:06:44 +0000] "GET / HTTP/1.1" 200 659 "-" "-" 2 "catapp@docker" "http://10.0.1.6:5000" 2ms
| 10.0.0.2 - - [11/Aug/2022:02:06:46 +0000] "GET / HTTP/1.1" 200 659 "-" "-" 3 "catapp@docker" "http://10.0.1.6:5000" 2ms
| 10.0.0.2 - - [11/Aug/2022:02:06:46 +0000] "GET / HTTP/1.1" 200 659 "-" "-" 4 "catapp@docker" "http://10.0.1.6:5000" 2ms
| 10.0.0.2 - - [11/Aug/2022:02:06:47 +0000] "GET / HTTP/1.1" 200 664 "-" "-" 5 "catapp@docker" "http://10.0.1.6:5000" 2ms

Invalid URLs​

Try causing a 404 error by requesting a missing page.

http://catapp.localhost/parkour
http://catapp.localhost/nowhere

Back in the terminal, check logs to see the 404 error recorded.

docker service logs traefik_traefik

Output:

| 10.0.0.2 - - [11/Aug/2022:02:10:18 +0000] "GET / HTTP/1.1" 200 659 "-" "-" 9 "catapp@docker" "http://10.0.1.6:5000" 2ms
| 10.0.0.2 - - [11/Aug/2022:02:10:18 +0000] "GET / HTTP/1.1" 200 659 "-" "-" 10 "catapp@docker" "http://10.0.1.6:5000" 1ms
| 10.0.0.2 - - [11/Aug/2022:02:10:19 +0000] "GET / HTTP/1.1" 200 659 "-" "-" 11 "catapp@docker" "http://10.0.1.6:5000" 2ms
| 10.0.0.2 - - [11/Aug/2022:02:10:27 +0000] "GET /parkour HTTP/1.1" 404 5093 "-" "-" 12 "catapp@docker" "http://10.0.1.8:80" 5ms
| 10.0.0.2 - - [11/Aug/2022:02:10:36 +0000] "GET /nowhere HTTP/1.1" 404 5093 "-" "-" 13 "catapp@docker" "http://10.0.1.8:80" 3ms
| 10.0.0.2 - - [11/Aug/2022:02:10:41 +0000] "GET / HTTP/1.1" 200 659 "-" "-" 14 "catapp@docker" "http://10.0.1.6:5000" 2ms
| 10.0.0.2 - - [11/Aug/2022:02:10:52 +0000] "GET /michaelscarn HTTP/1.1" 404 5093 "-" "-" 15 "catapp@docker" "http://10.0.1.8:80" 5ms
| 10.0.0.2 - - [11/Aug/2022:02:10:56 +0000] "GET / HTTP/1.1" 200 659 "-" "-" 16 "catapp@docker" "http://10.0.1.6:5000" 3ms

Authentication Enabled​

Now we’ll test how access logs work when authentication is turned on.

  • Uses the users_file for credentials
  • Requires entering valid username and password
  • Logs also capture failed authentication attempts

Here’s the configuration file:

docker-compose.auth-log.yml
version: "3"

services:
  traefik:
    image: traefik:v2.3
    ports:
      - "80:80"
      - "443:443"
      - "8080:8080"
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock
      - ./traefik.access-log.yml:/etc/traefik/traefik.yml
      - ./users_file:/users_file:ro # <-- mount your users file here

  catapp:
    image: mikesir87/cats:1.0
    labels:
      - "traefik.enable=true"
      # Routers
      - "traefik.http.routers.catapp.rule=Host(`catapp.localhost`)"
      - "traefik.http.routers.catapp.service=catapp"
      - "traefik.http.routers.catapp.entrypoints=web"
      # - "traefik.http.routers.catapp.middlewares=test-compress,test-errorpages"
      - "traefik.http.routers.catapp.middlewares=test-auth,test-compress,test-errorpages"
      # Services
      - "traefik.http.services.catapp.loadbalancer.server.port=5000"
      # Middleware BasicAuth using users_file
      - "traefik.http.middlewares.test-auth.basicauth.usersfile=/users_file"
      # Compress Middleware
      - "traefik.http.middlewares.test-compress.compress=true"
      # Error Pages Middleware
      - "traefik.http.middlewares.test-errorpages.errors.status=400-599"
      - "traefik.http.middlewares.test-errorpages.errors.service=error"
      - "traefik.http.middlewares.test-errorpages.errors.query=/{status}.html"

  # Error Page service
  error:
    image: guillaumebriday/traefik-custom-error-pages
    labels:
      - "traefik.enable=true"
      - "traefik.http.routers.error.rule=Host(`error.localhost`)"
      - "traefik.http.routers.error.service=error"
      - "traefik.http.services.error.loadbalancer.server.port=80"
      - "traefik.http.routers.error.entrypoints=web"

Before starting, ensure the following files are present:

├── docker-compose.access-log.yml     # not needed for this step
├── docker-compose.auth-log.yml
├── traefik.access-log.yml
└── users_file

Stop any previous stack:

docker stack rm traefik

Make sure the rm command returns the output below. You might need to wait a few minutes or try running it a few times.

Nothing found in stack: traefik

Then deploy the new stack:

docker stack deploy -c  docker stack deploy -c docker-compose.auth-log.yml traefik

Open the browser once again. Enter the credentials when prompted. You can also try entering an invalid user.

In your terminal, check the logs:

docker service logs traefik_traefik

You should see output showing both failed and successful login attempts:

| 10.0.0.2 - - [11/Aug/2022:03:17:29 +0000] "GET / HTTP/1.1" 401 17 "-" "-" 1 "catapp@docker" "-" 0ms
| 10.0.0.2 - - [11/Aug/2022:03:17:29 +0000] "GET / HTTP/1.1" 401 17 "-" "-" 2 "catapp@docker" "-" 0ms
| 10.0.0.2 - hackerman [11/Aug/2022:03:17:37 +0000] "GET / HTTP/1.1" 401 17 "-" "-" 3 "catapp@docker" "-" 0ms
| 10.0.0.2 - toby [11/Aug/2022:03:17:42 +0000] "GET / HTTP/1.1" 401 17 "-" "-" 4 "catapp@docker" "-" 0ms
| 10.0.0.2 - micahelscarn [11/Aug/2022:03:18:06 +0000] "GET / HTTP/1.1" 401 17 "-" "-" 5 "catapp@docker" "-" 0ms
| 10.0.0.2 - michaelscarn [11/Aug/2022:03:18:12 +0000] "GET / HTTP/1.1" 200 659 "-" "-" 6 "catapp@docker" "http://10.0.1.3:5000" 10ms
| 10.0.0.2 - michaelscarn [11/Aug/2022:03:18:12 +0000] "GET /favicon.ico HTTP/1.1" 404 5093 "-" "-" 7 "catapp@docker" "http://10.0.1.6:80" 7ms
| 10.0.0.2 - michaelscarn [11/Aug/2022:03:18:17 +0000] "GET / HTTP/1.1" 200 659 "-" "-" 8 "catapp@docker" "http://10.0.1.3:5000" 2ms
| 10.0.0.2 - michaelscarn [11/Aug/2022:03:18:18 +0000] "GET / HTTP/1.1" 200 659 "-" "-" 9 "catapp@docker" "http://10.0.1.3:5000" 2ms
| 10.0.0.2 - michaelscarn [11/Aug/2022:03:18:18 +0000] "GET / HTTP/1.1" 200 659 "-" "-" 10 "catapp@docker" "http://10.0.1.3:5000" 2ms

Filtering Access Logs​

You can also filter logs to only show certain status codes, like 404 errors.

In the traefik.filter-log.yml below, we are filtering...

traefik.filter-log.yml
api:
  dashboard: true
  insecure: true

providers:
  docker:
    exposedByDefault: false


# Configuring Multiple Filters
accessLog:
  filters:
    statusCodes:
      - "404"
    retryAttempts: true
    minDuration: "10ms"

log:
  level: INFO

entryPoints:
  web:
    address: ":80"
  websecure:
    address: ":443"

Delete the previous stack:

docker stack rm traefik

Re-run the rm command until it returns;

Nothing found in stack: traefik

Then deploy the stack using docker-compose.filter-log.yml:

docker stack deploy -c docker-compose.filter-log.yml traefik
info

The docker-compose.filter-log.yml is similar with the previous DOcker compose file but it is configured to use the traefik.filter-log.yml

Open the browser again and try these steps:

  • Enter an invalid credentials
  • Enter a valid credentials
  • Refresh the page a few times
  • Add /photos to the URL to trigger a 404

These steps create a mix of failed logins, successful logins, and missing page errors:

Checking the logs:

docker service logs traefik_traefik

Now the output only shows entries that match the configured filters (404 status, retry attempts, and requests taking at least 10ms):

| 10.0.0.2 - michaelscarn [11/Aug/2022:03:34:58 +0000] "GET / HTTP/1.1" 200 659 "-" "-" 3 "catapp@docker" "http://10.0.1.6:5000" 10ms
| 10.0.0.2 - michaelscarn [11/Aug/2022:03:34:58 +0000] "GET /favicon.ico HTTP/1.1" 404 5093 "-" "-" 4 "catapp@docker" "http://10.0.1.8:80" 4ms
| 10.0.0.2 - michaelscarn [11/Aug/2022:03:35:14 +0000] "GET /photos HTTP/1.1" 404 5093 "-" "-" 9 "catapp@docker" "http://10.0.1.8:80" 5ms

Cleanup​

Delete the deployed stack:

docker stack rm traefik

You can also delete the users_file:

rm -f users_file
